4. Measuring Power on the
Cyclone III Starter Board
Introduction
One of the main features of the Cyclone ? III device is its low power
consumption. You can measure the power of the 3C25 device on the
Cyclone III starter board under various conditions with an example
design provided with the kit.
The power example design allows you to control the amount of logic
utilized in the FPGA, the clock frequency, the number of I/Os being used,
and measure the effect on the power to the Cyclone III device. Because the
Cyclone III starter board has only four buttons and four LEDs, interaction
with the board is minimal as defined below.
Table 4–1 describes the functionality of the four input buttons that control
the power example design.
Table 4–1. Four Input Button Functionality
Button
1
FPGA Pin
F1
Reset
Type
Description
Resets the demo to the beginning, node
i_nrst .
2
F2
Toggle
Advances the example design to the next higher
frequency, node i_nfreq_next .
3
A10
Toggle
Advances the example design to the next higher
resource utilization, node_i_nperc_next .
4
B10
Press and Hold
Enables the outputs to toggle, node
i_noutput_ena .
Tables 4–2 and 4–3 describe how the LEDs indicate the example design’s
current power state.
Table 4–2. LEDs Power State (Frequency)
Displays
Frequency
MSB
LED2
LEDs
LSB
LED1
State
00
Clock Frequency
(MHz)
0
01
10
11
33
67
100
Altera Corporation
Core Version a.b.c variable
4–1
July 2010
Preliminary
